MT/ MTH
5-Axis Gantry Machining Center
The MT and MTH series are designed for 5-axis machining of large and complex structural components. While the MT models are designed for high dynamics and productive aluminum machining, the MTH series offers the required rigidity and machining performance for steel, titanium and high-temperature resistant materials.
Different sizes, spindle configurations and swivel heads enable an application-specific design for demanding aerospace components.
Key Benefits:
Wide range of applications from high-speed to heavy-duty machining
Generous working area for large and complex structural components
High table loads for large-format and heavy workpieces
Dynamic and precise 5-axis machining of complex geometries
Application-specific spindle and swivel head configurations
High axis accuracy thanks to optical measuring systems on all five axes
Precision-scraped contact surfaces support high geometric accuracy of the machine structure.
Technical Details:
*Options available
| Machine model | MT1520/30 | MT2432/42 | MTH2432/42/62 | MTH2842/62 |
|---|---|---|---|---|
| Number of axes | 5 | |||
| X/Y/Z Travel [mm]* | 2000 (3000)/2000/850 | 3200 (4200)/3000/1000 | 3200 (4200, 6200)/3000/1000 | 4200 (6200)/3500/1000 |
| X/Y/Z Feed Rate [m/min] | 30/30/30 | 20/20/20 | ||
| Max. table load [kg] | 3,000/5,000 | 14,000 | 16,000 | |
| Table size [mm] | 2,100 (3,100) x 1,200 | 3,000 (4,000) x 2,060 | 3,000 (4,000, 6,000) x 2,060 | 4,000 (6,000) x 2,500 |
| Spindle (Motorized Spindle)* | 24,000 rpm, 60/75 kW, 48/60 Nm | 24,000 rpm, 35/42 kW, 55/67 Nm | 12,000 rpm, 50/78.5 kW, 318/500 Nm | |
| Tool holder* | HSK63A | HSK100A | ||
| Tool capacity* | 32 | |||
| NC control* | Siemens One | |||
Typical Components
Wing ribs, spars, crossbeams, pylons, and large, complex fuselage and wing structural components.
By loading this video, you agree to Google's and YouTube's privacy policies.
Spindle Charts
Machine Dimensions
